From specification to implementation.
End-to-end development of inspection and measurement tooling for the automotive industry — design, manufacturing, metrology, delivery and implementation support.
Complete process.
We take responsibility for the full workflow: from requirement analysis and collaborative design refinement to a finished tool verified through dimensional inspection.
At the client's request, we also support implementation of the tooling in the target manufacturing process.
Design
We design in CATIA, Autodesk Inventor or, if required, the customer's specified CAD environment, taking production ergonomics, repeatability and measurement conditions into account.
Manufacturing
Production is carried out using our available machine-tool network and manufacturing infrastructure, with the process selected for geometry, tolerance and material requirements.
Final inspection
Finished tooling can be verified on a coordinate measuring machine (CMM) or with an optical scanner, depending on geometry and tolerance requirements.
Polyurethane
Used where surface replication, operational durability and safe contact with the inspected component are important.
Aluminium
Used in rigid, precise tooling structures as well as datum, support and fixture components.
